6x 100GE ZQSFP25 slots and 16x 10GE SFP+ slots, 2 x GE RJ45 Management Ports, SPU NP6 and CP9 hardware accelerated, 800 GB SSD onboard storage, and 3 AC power supplies.
6x 100GE ZQSFP25 slots and 16x 10GE SFP+ slots, 2 x GE RJ45 Management Ports, SPU NP6 and CP9 hardware accelerated, 800 GB SSD onboard storage, and 3 AC power supplies.
13.5 Gbps
30 Gbps
Multiple 40/100 GE QSFP+/QSFP28, 10 GE SFP+ and GE RJ45
| Model | FG-3980E /-DC FG-3960E /-DC |
| Interfaces and Modules | |
| 40/100 GE QSFP+/QSFP28 Slots | 10/6 |
| 40 GE QSFP+ Slots | – |
| 10 GE SFP+ Slots | 16 |
| GE RJ45 Management Ports | 2 |
| USB Ports | 1 |
| Console Port | 1 |
| Internal Storage | - |
| Included Transceivers | 2x SFP+ (SR 10 GE) |
| System Performance and Capacity | |
| Firewall Throughput (Packet per Second) | 1,020 Mpps/555 Mpps |
| Firewall Latency (64 byte, UDP) | 3 µs |
| Firewall Throughput (Packet per Second) | 1,020 Mpps/555 Mpps |
| Concurrent Sessions (TCP) | 160 Million |
| New Sessions/Sec (TCP) | 550,000 |
| Firewall Policies | 200,000 |
| Concurrent SSL-VPN Users (Recommended Maximum) | 30,000 |
| IPS Throughput (HTTP / Enterprise Mix) | 75 / 21 Gbps |
| SSL Inspection Throughput | 32 Gbps 30 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 30,000/30,000 |
| CAPWAP Throughput | 14 Gbps/13.5 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 500 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 4,096 / 1,024 |
| Maximum Number of FortiTokens | 5,000 |
| Maximum Number of Registered FortiClients | 100,000 |
| High Availability Configurations | Active / Active, Active / Passive, Clustering |
| Dimensions and Power | |
| Height x Width x Length (mm) | 222 x 437 x 695 |
| Weight | 26.8 kg |
| Form Factor | 5 RU |
| AC Power Supply | 100–240V AC, 50–60 Hz |
| DC | 48–60V |
| Power Consumption (Average / Maximum) | 1172 / 2350 W 960 / 2110 W |
| Current (Maximum) | 23.5A@100V, 9.8A@240V 21.1A@100V, 8.8A@240V |
| Heat Dissipation | 8,019 BTU/h 7,200 BTU/h |
| Redundant Power Supplies | Yes, Hot Swappable |
| Operating Environment and Certifications | |
| Operating Temperature | 0–40°C |
| Storage Temperature | -35–70°C |
| Humidity | 10–90% non-condensing |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 |
| FG-3960E-BDL-988-12 | FortiGate-3960E Hardware plus 1 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection |
| FG-3960E-BDL-988-36 | FortiGate-3960E Hardware plus 3 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection |
| FG-3960E-BDL-988-60 | FortiGate-3960E Hardware plus 5 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection |
| FG-3960E-BDL-980-12 | FortiGate-3960E Hardware plus 1 Year 24x7 FortiCare and FortiGuard Enterprise Protection |
| FG-3960E-BDL-980-36 | FortiGate-3960E Hardware plus 3 Year 24x7 FortiCare and FortiGuard Enterprise Protection |
| FG-3960E-BDL-980-60 | FortiGate-3960E Hardware plus 5 Year 24x7 FortiCare and FortiGuard Enterprise Protection |
| FG-3960E-BDL-950-12 | FortiGate-3960E Hardware plus 1 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-BDL-950-36 | FortiGate-3960E Hardware plus 3 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-BDL-950-60 | FortiGate-3960E Hardware plus 5 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-BDL-900-36 | FortiGate-3960E Hardware plus 3 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-BDL-900-60 | FortiGate-3960E Hardware plus 5 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-BDL | FortiGate-3960E Hardware plus 1 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-DC-BDL-988-12 | FortiGate-3960E-DC Hardware plus 1 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection |
| FG-3960E-DC-BDL-988-36 | FortiGate-3960E-DC Hardware plus 3 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection |
| FG-3960E-DC-BDL-988-60 | FortiGate-3960E-DC Hardware plus 5 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection |
| FG-3960E-DC-BDL-980-12 | FortiGate-3960E-DC Hardware plus 1 Year 24x7 FortiCare and FortiGuard Enterprise Protection |
| FG-3960E-DC-BDL-980-36 | FortiGate-3960E-DC Hardware plus 3 Year 24x7 FortiCare and FortiGuard Enterprise Protection |
| FG-3960E-DC-BDL-980-60 | FortiGate-3960E-DC Hardware plus 5 Year 24x7 FortiCare and FortiGuard Enterprise Protection |
| FG-3960E-DC-BDL-950-12 | FortiGate-3960E-DC Hardware plus 1 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-DC-BDL-950-36 | FortiGate-3960E-DC Hardware plus 3 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-DC-BDL-950-60 | FortiGate-3960E-DC Hardware plus 5 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-DC-BDL-900-36 | FortiGate-3960E-DC Hardware plus 3 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-DC-BDL-900-60 | FortiGate-3960E-DC Hardware plus 5 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection |
| FG-3960E-DC-BDL | FortiGate-3960E-DC Hardware plus 1 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection |
| FC-10-03961-100-02-12 | FortiGate-3960E 1 Year FortiGuard Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiSandbox Cloud Service |
| FC-10-03961-108-02-12 | FortiGate-3960E 1 Year FortiGuard IPS Service |
| FC-10-03961-112-02-12 | FortiGate-3960E 1 Year FortiGuard Web Filtering Service |
| FC-10-03961-159-02-12 | FortiGate-3960E 1 Year FortiGuard Industrial Security Service |
| FC-10-03961-175-02-12 | FortiGate-3960E 1 Year FortiGuard Security Rating Service |
| FC-10-03961-311-02-12 | FortiGate-3960E 1 Year 8x5 FortiCare Contract |
| FC-10-03961-311-02-36 | FortiGate-3960E 3 Year 8x5 FortiCare Contract |
| FC-10-03961-311-02-60 | FortiGate-3960E 5 Year 8x5 FortiCare Contract |
| FC-10-03961-247-02-12 | FortiGate-3960E 1 Year 24x7 FortiCare Contract |
| FC-10-03961-247-02-36 | FortiGate-3960E 3 Year 24x7 FortiCare Contract |
| FC-10-03961-247-02-60 | FortiGate-3960E 5 Year 24x7 FortiCare Contract |
| FC-10-03961-284-02-12 | FortiGate-3960E 1 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling) |
| FC-10-03961-284-02-36 | FortiGate-3960E 3 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling) |
| FC-10-03961-284-02-60 | FortiGate-3960E 5 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling) |
| FC-10-03960-100-02-12 | FortiGate-3960E-DC 1 Year FortiGuard Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiSandbox Cloud Service |
| FC-10-03960-108-02-12 | FortiGate-3960E-DC 1 Year FortiGuard IPS Service |
| FC-10-03960-112-02-12 | FortiGate-3960E-DC 1 Year FortiGuard Web Filtering Service |
| FC-10-03960-159-02-12 | FortiGate-3960E-DC 1 Year FortiGuard Industrial Security Service |
| FC-10-03960-175-02-12 | FortiGate-3960E-DC 1 Year FortiGuard Security Rating Service |
| FC-10-03960-311-02-12 | FortiGate-3960E-DC 1 Year 8x5 FortiCare Contract |
| FC-10-03960-311-02-36 | FortiGate-3960E-DC 3 Year 8x5 FortiCare Contract |
| FC-10-03960-311-02-60 | FortiGate-3960E-DC 5 Year 8x5 FortiCare Contract |
| FC-10-03960-247-02-12 | FortiGate-3960E-DC 1 Year 24x7 FortiCare Contract |
| FC-10-03960-247-02-36 | FortiGate-3960E-DC 3 Year 24x7 FortiCare Contract |
| FC-10-03960-247-02-60 | FortiGate-3960E-DC 5 Year 24x7 FortiCare Contract |
| FC-10-03960-284-02-12 | FortiGate-3960E-DC 1 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling) |
| FC-10-03960-284-02-36 | FortiGate-3960E-DC 3 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling) |
| FC-10-03960-284-02-60 | FortiGate-3960E-DC 5 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling) |
