Межсетевой экран Fortigate 3600E

Interfaces and Modules

100 GE QSFP28 / 40 GE QSFP+ Slots

6

25 GE SFP28 / 10 GE SFP+ / GE SFP Slots

32

GE RJ45 Management Ports

2 (supports 1 GE only)

USB Ports (Client / Server)

1 / 1

Console Port

1

Internal Storage

2x 2 TB SSD (For FG-3601E only)

Included Transceivers

2x SFP+ (SR 10GE)

System Performance — Enterprise Traffic Mix

IPS Throughput ²

55 Gbps

NGFW Throughput ^{2, 4}

40 Gbps

Threat Protection Throughput ^{2, 5}

30 Gbps

System Performance and Capacity

Firewall Throughput (1518 / 512 / 64 byte, UDP)

240 / 240 / 150 Gbps

IPv6 Firewall Throughput  (1518 / 512 / 86 byte, UDP)

240 / 240 / 150 Gbps

Firewall Latency (64 byte, UDP)

4 µs

Firewall Throughput (Packet per Second)

225 Mpps

Concurrent Sessions (TCP)

50 Million

New Sessions/Second (TCP)

460,000

Firewall Policies

200,000

IPsec VPN Throughput (512 byte) ¹

145 Gbps

Gateway-to-Gateway IPsec VPN Tunnels

40,000

Client-to-Gateway IPsec VPN Tunnels

200,000

SSL-VPN Throughput

12 Gbps

Concurrent SSL-VPN Users

(Recommended Maximum, Tunnel Mode)

30,000

SSL Inspection Throughput (IPS, avg. HTTPS) ³

34 Gbps

SSL Inspection CPS (IPS, avg. HTTPS) ³

19,000

SSL Inspection Concurrent Session  (IPS, avg. HTTPS) ³

5.2 Million

Application Control Throughput (HTTP 64K) ²

95 Gbps

CAPWAP Throughput (HTTP 64K)

57 Gbps

Virtual Domains (Default / Maximum)

10 / 500

Maximum Number of FortiSwitches Supported

256

Maximum Number of FortiAPs  (Total / Tunnel Mode)

4,096 / 1,024
