Межсетевой экран Fortigate 3800D

4x 100G CFP2 slots, 4x 40G QSFP+ slots, and 8x 10G SFP+ slots, 2 x GE RJ45 Management, FortiASIC NP6 and CP8 hardware accelerated, 960 GB onboard storage, and dual AC power supplies.

4x 100G CFP2 slots, 4x 40G QSFP+ slots, and 8x 10G SFP+ slots, 2 x GE RJ45 Management, FortiASIC NP6 and CP8 hardware accelerated, 960 GB onboard storage, and dual AC power supplies.

Slider

Защита трафика

13 Gbps

Проверка SSL

23 Gbps

Сетевые интерфейсы

Multiple 100 GE CFP2, 40 GE QSFP+, 10 GE SFP+ and/or multiple GE SFP/RJ45 depending on variants

Interfaces and Modules
100 GE CFP2 Slots 4
40 GE QSFP+ Slots 4
10 GE SFP+ Slots 8 (supports GE SFP as well)
GE RJ45 Management Ports 2
USB Ports 1
Console Port 1
Internal Storage 960 GB
Included Transceivers 2x SFP+ (SR 10 GE)
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte, UDP) 320 / 300 / 150 Gbps
Firewall Latency (64 byte, UDP) 5 µs
Firewall Throughput (Packet per Second) 262.5 Mpps
Concurrent Sessions (TCP) 95 Million
New Sessions/Sec (TCP) 480,000
Firewall Policies 200,000
IPsec VPN Throughput (512 byte) 135 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 40,000
Client-to-Gateway IPsec VPN Tunnels 64,000
SSL-VPN Throughput 10 Gbps
Concurrent SSL-VPN Users (Recommended Maximum) 30,000
IPS Throughput (HTTP / Enterprise Mix) 75 / 21 Gbps
SSL Inspection Throughput 23 Gbps
Application Control Throughput 44 Gbps
NGFW Throughput 17 Gbps
Threat Protection Throughput 12 Gbps
CAPWAP Throughput 22 Gbps
Virtual Domains (Default / Maximum) 10 / 500
Maximum Number of FortiAPs (Total / Tunnel Mode) 4,096 / 1,024
Maximum Number of FortiTokens 5,000
Maximum Number of Registered FortiClients 20,000
High Availability Configurations Active / Active, Active / Passive, Clustering
Dimensions and Power
Height x Width x Length (mm) 133 x 442 x 673
Weight 23.0 kg
Form Factor 3 RU
AC Power Supply 100–240V AC, 60–50 Hz
DC 48–72V DC
Power Consumption (Average / Maximum) 536 / 768 W
Current (Maximum) 12A@100V, 5A@240V
Heat Dissipation 2621 BTU/h
Redundant Power Supplies Yes, Hot Swappable
Operating Environment and Certifications
Operating Temperature 0–40°C
Storage Temperature -35–70°C
Humidity 20–90% non-condensing
Operating Altitude Up to 7,400 ft (2,250 m)
Compliance FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6

FG-3800D-BDL-988-12 FortiGate-3800D Hardware plus 1 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection
FG-3800D-BDL-988-36 FortiGate-3800D Hardware plus 3 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection
FG-3800D-BDL-988-60 FortiGate-3800D Hardware plus 5 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection
FG-3800D-BDL-980-12 FortiGate-3800D Hardware plus 1 Year 24x7 FortiCare and FortiGuard Enterprise Protection
FG-3800D-BDL-980-36 FortiGate-3800D Hardware plus 3 Year 24x7 FortiCare and FortiGuard Enterprise Protection
FG-3800D-BDL-980-60 FortiGate-3800D Hardware plus 5 Year 24x7 FortiCare and FortiGuard Enterprise Protection
FG-3800D-BDL-950-12 FortiGate-3800D Hardware plus 1 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-BDL-950-36 FortiGate-3800D Hardware plus 3 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-BDL-950-60 FortiGate-3800D Hardware plus 5 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-BDL-900-36 FortiGate-3800D Hardware plus 3 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-BDL-900-60 FortiGate-3800D Hardware plus 5 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-BDL FortiGate-3800D Hardware plus 1 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-DC-BDL-988-12 FortiGate-3800D-DC Hardware plus 1 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection
FG-3800D-DC-BDL-988-36 FortiGate-3800D-DC Hardware plus 3 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection
FG-3800D-DC-BDL-988-60 FortiGate-3800D-DC Hardware plus 5 Year Hardware plus ASE FortiCare and FortiGuard 360 Protection
FG-3800D-DC-BDL-980-12 FortiGate-3800D-DC Hardware plus 1 Year 24x7 FortiCare and FortiGuard Enterprise Protection
FG-3800D-DC-BDL-980-36 FortiGate-3800D-DC Hardware plus 3 Year 24x7 FortiCare and FortiGuard Enterprise Protection
FG-3800D-DC-BDL-980-60 FortiGate-3800D-DC Hardware plus 5 Year 24x7 FortiCare and FortiGuard Enterprise Protection
FG-3800D-DC-BDL-950-12 FortiGate-3800D-DC Hardware plus 1 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-DC-BDL-950-36 FortiGate-3800D-DC Hardware plus 3 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-DC-BDL-950-60 FortiGate-3800D-DC Hardware plus 5 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-DC-BDL-900-36 FortiGate-3800D-DC Hardware plus 3 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-DC-BDL-900-60 FortiGate-3800D-DC Hardware plus 5 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection
FG-3800D-DC-BDL FortiGate-3800D-DC Hardware plus 1 Year 8x5 FortiCare and FortiGuard Unified (UTM) Protection

FC-10-3K8HD-100-02-12 FortiGate-3800D 1 Year FortiGuard Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiSandbox Cloud Service
FC-10-3K8HD-108-02-12 FortiGate-3800D 1 Year FortiGuard IPS Service
FC-10-3K8HD-112-02-12 FortiGate-3800D 1 Year FortiGuard Web Filtering Service
FC-10-3K8HD-159-02-12 FortiGate-3800D 1 Year FortiGuard Industrial Security Service
FC-10-3K8HD-175-02-12 FortiGate-3800D 1 Year FortiGuard Security Rating Service
FC-10-3K8HD-311-02-12 FortiGate-3800D 1 Year 8x5 FortiCare Contract
FC-10-3K8HD-311-02-36 FortiGate-3800D 3 Year 8x5 FortiCare Contract
FC-10-3K8HD-311-02-60 FortiGate-3800D 5 Year 8x5 FortiCare Contract
FC-10-3K8HD-247-02-12 FortiGate-3800D 1 Year 24x7 FortiCare Contract
FC-10-3K8HD-247-02-36 FortiGate-3800D 3 Year 24x7 FortiCare Contract
FC-10-3K8HD-247-02-60 FortiGate-3800D 5 Year 24x7 FortiCare Contract
FC-10-3K8HD-284-02-12 FortiGate-3800D 1 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
FC-10-3K8HD-284-02-36 FortiGate-3800D 3 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
FC-10-3K8HD-284-02-60 FortiGate-3800D 5 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
FC-10-3K8DD-100-02-12 FortiGate-3800D-DC 1 Year FortiGuard Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiSandbox Cloud Service
FC-10-3K8DD-108-02-12 FortiGate-3800D-DC 1 Year FortiGuard IPS Service
FC-10-3K8DD-112-02-12 FortiGate-3800D-DC 1 Year FortiGuard Web Filtering Service
FC-10-3K8DD-159-02-12 FortiGate-3800D-DC 1 Year FortiGuard Industrial Security Service
FC-10-3K8DD-175-02-12 FortiGate-3800D-DC 1 Year FortiGuard Security Rating Service
FC-10-3K8DD-311-02-12 FortiGate-3800D-DC 1 Year 8x5 FortiCare Contract
FC-10-3K8DD-311-02-36 FortiGate-3800D-DC 3 Year 8x5 FortiCare Contract
FC-10-3K8DD-311-02-60 FortiGate-3800D-DC 5 Year 8x5 FortiCare Contract
FC-10-3K8DD-247-02-12 FortiGate-3800D-DC 1 Year 24x7 FortiCare Contract
FC-10-3K8DD-247-02-36 FortiGate-3800D-DC 3 Year 24x7 FortiCare Contract
FC-10-3K8DD-247-02-60 FortiGate-3800D-DC 5 Year 24x7 FortiCare Contract
FC-10-3K8DD-284-02-12 FortiGate-3800D-DC 1 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
FC-10-3K8DD-284-02-36 FortiGate-3800D-DC 3 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
FC-10-3K8DD-284-02-60 FortiGate-3800D-DC 5 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
